Ref. 25015

DIE HSS DIN EN22568

P				M		K			N				S		H
>800	>1.000	>1.200	>1.400	>950	>1.200	>500	>800	>1.400	Al	Cu	Mg/Zn	Plastic	Ti	Ni	50 HRC	55 HRC	60 HRC

Vc (m/mm)
Best
Alternative

Technical Features:

High Speed Steel HSS
Tolerance 6g
Left hande

Applications:

Soft magnetic steels, construction and cementation steels, and non-alloy and alloy carbon steels up to a strength of 800N / mm2

Code	Ø (mm)	L (mm)	l (mm)
25015030520	M3.00x0.50	20	5	1
25015040720	M4.00x0.70	20	5	1
25015050820	M5.00x0.80	20	7	1
25015061020	M6.00x1.00	25	7	1
25015071025	M7.00x1.00	25	9	1
25015081025	M8.00x1.00	25	9	1
25015081225	M8.00x1.25	25	9	1
25015101030	M10.00x1.00	30	11	1
25015101230	M10.00x1.25	30	11	1
25015101530	M10.00x1.50	30	11	1
25015121238	M12.00x1.25	38	10	1
25015121538	M12.00x1.50	38	10	1
25015121738	M12.00x1.75	38	14	1
25015141538	M14.00x1.50	38	10	1
25015142038	M14.00x2.00	38	14	1
25015161545	M16.00x1.50	45	14	1
25015162045	M16.00x2.00	45	18	1
25015181545	M18.00x1.50	45	14	1
25015182545	M18.00x2.50	45	18	1
25015201545	M20.00x1.50	45	14	1
25015202545	M20.00x2.50	45	18	1
25015221555	M22.00x1.50	55	16	1
25015222555	M22.00x2.50	55	22	1
25015241555	M24.00x1.50	55	16	1
25015243055	M24.00x3.00	55	22	1
25015273065	M27.00x3.00	65	25	1
25015303565	M30.00x3.50	65	25	1
